TP-LINK VIGI NVR1008H-8MP | 8-CHANNEL POE+ NETWORK VIDEO RECORDER
FEATURES:
- 4K HDMI Video Output and 16MP Decoding Capacity – Sharp image definition up to 8MP and an 8-channel display ensures you capture every detail, from every angle
- Simplified Deployment with PoE+ – Easily connect and power your PoE camera with one RJ45 cable transmitting both data and power
- 8-Channel Simultaneous Playback – Replay the feed from up to 8 cameras at the same time, increase replay speed and find events in the video schedule to easily review footage
- H.265+ – Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads and reduce monitoring costs without sacrificing image quality
- ONVIF Ensures Compatibility – Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility
- Plug & Play – Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before
- 24/7 Continuous Recording – Stores up to 10TB of footage from connected cameras to secure your data for quick, convenient access
- Remote Monitoring – The dedicated VIGI App, web UI and VIGI Security Manager enable remote monitoring, providing ease and convenience
- Flexible Installation – Choose the suitable installation method by simply housing your NVR on a rack or placing it on or under a desk for greater convenience
- Two-Way Audio – With voice intercom support, carry two-way conversations while watching your feed from anywhere
9 in stock
TP-Link VIGI NVR1008H-8MP | 8-Channel PoE+ Network Video Recorder
Security Never Shuts Down
FEATURES:
- 4K HDMI Video Output and 16MP Decoding Capacity - Sharp image definition up to 8MP and an 8-channel display ensures you capture every detail, from every angle
- Simplified Deployment with PoE+ - Easily connect and power your PoE camera with one RJ45 cable transmitting both data and power
- 8-Channel Simultaneous Playback - Replay the feed from up to 8 cameras at the same time, increase replay speed and find events in the video schedule to easily review footage
- H.265+ - Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads and reduce monitoring costs without sacrificing image quality
- ONVIF Ensures Compatibility - Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility
- Plug & Play - Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before
- 24/7 Continuous Recording - Stores up to 10TB of footage from connected cameras to secure your data for quick, convenient access
- Remote Monitoring - The dedicated VIGI App, web UI and VIGI Security Manager enable remote monitoring, providing ease and convenience
- Flexible Installation - Choose the suitable installation method by simply housing your NVR on a rack or placing it on or under a desk for greater convenience
- Two-Way Audio - With voice intercom support, carry two-way conversations while watching your feed from anywhere
SPECIFICATIONS:
NETWORK | |
Protocol | TCP/IP, DHCP, DNS, NTP, UPnP |
Incoming Bandwith | 80Mbps |
Outgoing Bandwidth | 60Mbps |
GENERAL | |
Operating Temperature | -10~55°C |
Package Contents | VIGI Network Video Recorder |
Power Adapter | |
HDD Screws | |
Mouse | |
Quick Installation Guide | |
Dimensions (W × D × H) | 294 × 180 × 44mm |
PoE | Standard: 802.3af/at |
PoE Ports: Ports 1-8 | |
PoE Budget: 113W | |
External Power Supply | 53.5V DC/2.43 A |
Power Consumption | 4.82W (without disk) |
INTERFACES | |
Network Interface | 1× RJ45 10/100Mbps Self-Adaptive Ethernet Interface |
USB Interface | 2× USB2.0 |
HARD DISK | |
SATA | 1× SATA Interface |
Capacity | Up to 10TB |
VIDEO/IMAGE | |
Video Input | 8-Channel IP Video Input, up to 8MP Resolution |
Recording Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
HDMI Output Resolution | 1-Channel, Resolution: 3840 × 2160 @30Hz, 1920 × 1080 @60Hz, 1680 × 1050 @60Hz, 1440 × 900 @60Hz, 1280 × 1024 @60Hz, 1024 × 768 @60Hz, 1280 × 720 @60Hz |
VGA Output Resolution | 1-Channel, Resolution: 1920 × 1080 @60Hz,1680 × 1050 @60Hz, 1440 × 900 @60Hz, 1280 × 1024 @60Hz, 1280 × 720 @60Hz, 1024 × 768 @60Hz |
DECODING | |
Decoding Format | H.265+/H.265/ H.264+/H.264 |
Live View/Playback Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Synchronous Playback | 8-Channel |
Capability | 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
