TP-LINK TL-SG105-M2 AND TL-SG108-M2 | 5/8-PORT 2.5G DESKTOP SWITCHES
Available in 5-Port or 8-Port
FEATURES:
- Five/Eight 2.5Gbps Ports – 5/8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices and provide up to 25/40Gbps of switching capacity (Model Dependent)
- Super-Fast Connections – Provides super-fast connections to 2.5G NAS, 2.5G Server, gaming computer, 2.5G Wi-Fi 6 AP, 4K video and more
- Ideal for Various Scenarios – Built for LAN parties, home entertainment, small and home offices and instant transfer for workstations
- Hassle-Free Cabling – Instantly upgrade to 2.5Gbps without the need to upgrade to CAT6 wiring, reducing wiring costs and hassle
- Silent Operation – Industry-leading fanless design ensures silent operation, ideal for any home or business
- Plug and Play – Allows for easy deployment without the need for a technician
- Metal Casing – Durable metal casing and desktop/wall-mounting design are well-suited for different environments
TP-Link TL-SG105-M2 and TL-SG108-M2 | 5/8-Port 2.5G Desktop Switches
Available in 5-Port or 8-Port
Upgrade to a Super-Fast, Futuristic Network
FEATURES:
- Five/Eight 2.5Gbps Ports - 5/8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices and provide up to 25/40Gbps of switching capacity (Model Dependent)
- Super-Fast Connections - Provides super-fast connections to 2.5G NAS, 2.5G Server, gaming computer, 2.5G Wi-Fi 6 AP, 4K video and more
- Ideal for Various Scenarios - Built for LAN parties, home entertainment, small and home offices and instant transfer for workstations
- Hassle-Free Cabling - Instantly upgrade to 2.5Gbps without the need to upgrade to CAT6 wiring, reducing wiring costs and hassle
- Silent Operation - Industry-leading fanless design ensures silent operation, ideal for any home or business
- Plug and Play - Allows for easy deployment without the need for a technician
- Metal Casing - Durable metal casing and desktop/wall-mounting design are well-suited for different environments
SPECIFICATIONS:
| HARDWARE FEATURES | ||
| Standards and Protocols |
IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3bz
|
|
| Interface |
5× 100Mbps/1Gbps/2.5Gbp Ports, Auto-Negotiation, Auto-MDI/MDIX
|
8× 100Mbps/1Gbps/2.5Gbp Ports, Auto-Negotiation, Auto-MDI/MDIX
|
| Fan Quantity |
Fanless
|
|
| External Power Supply |
External Power Adapter (Output: 12VDC 1A)
|
External Power Adapter (Output: 12VDC 1.5A)
|
| LED Indicator |
System Power: 1
|
|
| Link/Act Indicators: 5, 1 indicator per port built into each RJ45 port | Link/Act Indicators: 8, 1 indicator per port built into each RJ45 port | |
| Dimensions (W × D × H) |
209 × 126 × 26mm
|
226 × 131 × 35mm
|
| Max Power Consumption |
12.11W
|
15.65W
|
| Max Heat Dissipation |
41.32 BTU/h
|
53.40 BTU/h
|
| PERFORMANCE | ||
| Switching Capacity |
25Gbps
|
40Gbps
|
| Packet Forwarding Rate |
18.6Mpps
|
29.8Mpps
|
| MAC Address Table |
16K
|
|
| Packet Buffer Memory |
1.5Mb
|
|
| Jumbo Frame |
10KB
|
|
| SOFTWARE FEATURES | ||
| Advanced Features |
802.3X Flow Control
|
|
| 802.1p/DSCP QoS | ||
| Transfer Method |
Store and Forward
|
|
| OTHERS | ||
| Certification |
CE, FCC ,RoHS
|
|
| Package Contents |
TL-SG105-M2: 5-Port 2.5G Multi-Gigabit Desktop Switch
|
TL-SG108-M2: 8-Port 2.5G Multi-Gigabit Desktop Switch
|
| Power Adapter | ||
| Installation Guide | ||
| Rubber Feet | ||
| Environment |
Operating Temperature: 0°C~40°C
|
|
| Storage Temperature: -40°C~70°C | ||
| Operating Humidity: 10–90% RH non-condensing | ||
| Storage Humidity: 5–90% RH non-condensing | ||
