TP-LINK ER707-M2 | OMADA MULTI-GIGABIT VPN ROUTER
FEATURES:
- Two 2.5G Ports – 1× 2.5G WAN and 1× 2.5G WAN/LAN ports provide high-bandwidth aggregation connectivity
- Up to 6× WAN Ports – 2.5G RJ45, Gigabit fibre and gigabit RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband
- Highly Secure VPN – Enterprise-standard SSL/IPSec/GER§/PPTP/L2TP VPN and OpenVPN are ideal for use across multiple branches and for WFH
- Integrated into Omada SDN – Supports Zero-Touch Provisioning (ZTP), Centralized Cloud Management, Intelligent Monitoring and more
- Centralized Management – Cloud access and Omada App provide the utmost in management convenience
- Extensive Security Features – Protect your network and data with advanced firewall policies, DoS defense, IP/MAC/URL filtering and more security functions
2 in stock
TP-Link ER707-M2 | Omada Multi-Gigabit VPN Router
High-Security VPN
FEATURES:
- Two 2.5G Ports - 1× 2.5G WAN and 1× 2.5G WAN/LAN ports provide high-bandwidth aggregation connectivity
- Up to 6× WAN Ports - 2.5G RJ45, Gigabit fibre and gigabit RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband
- Highly Secure VPN - Enterprise-standard SSL/IPSec/GER§/PPTP/L2TP VPN and OpenVPN are ideal for use across multiple branches and for WFH
- Integrated into Omada SDN - Supports Zero-Touch Provisioning (ZTP), Centralized Cloud Management, Intelligent Monitoring and more
- Centralized Management - Cloud access and Omada App provide the utmost in management convenience
- Extensive Security Features - Protect your network and data with advanced firewall policies, DoS defense, IP/MAC/URL filtering and more security functions
SPECIFICATIONS:
| SECURITY | |
| Access Control | Source/Destination IP Based Access Control |
| Filtering | WEB Group Filtering |
| URL Filtering | |
| Web Security | |
| ARP Inspection | Sending GARP Packets |
| ARP Scanning | |
| IP-MAC Binding | |
| Attack Defense | TCP/UDP/ICMP Flood Defense |
| Block TCP Scan (Stealth FIN/Xmas/Null) | |
| Block Ping from WAN | |
| HARDWARE FEATURES | |
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q |
| TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP | |
| Interface | 1× 2.5G RJ45 WAN Port |
| 1× 2.5G RJ45 WAN/LAN Port | |
| 1× Gigabit SFP WAN/LAN Port | |
| 4× Gigabit RJ45 WAN/LAN Ports | |
| 1× USB2.0 Port (Supports USB storage and LTE backup with LTE dongle) | |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max. 100 m) EIA/TIA-568 100Ω STP (Max. 100 m) |
| 100BASE-TX: UTP category 5, 5e cable (Max. 100 m) EIA/TIA-568 100Ω STP (Max. 100 m) | |
| 1000BASE-T: UTP category 5, 5e, 6 cable (Max. 100 m) | |
| 2500BASE-T: UTP category 5, 5e, 6 cable (Max. 100 m) | |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply | 12V/1.5A Adapter |
| PoE Budget | - |
| Flash | 128MB NAND |
| DRAM | 1GB DDR4 |
| LED | PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| Dimensions (W × D × H) | 226 × 131 × 35mm |
| Protection | 4kV Surge Protection |
| Enclosure | Steel |
| Mounting | Desktop/Wall Mounting |
| Max. Power Consumption | 14.2W (with USB2.0 connected) |
| 7.1W (without USB2.0 connected) | |
| PERFORMANCE | |
| Concurrent Session | 500,000 |
| New Sessions/Second | 4,200 |
| NAT (Static IP) | 2364.45Mbps / 2343.28Mbps |
| NAT(DHCP) | 2364.24Mbps / 2326.21Mbps |
| NAT(PPPoE) | 2350.93Mbps / 2125.83Mbps |
| NAT (L2TP) | 1249.04Mbps / 831.12Mbps |
| NAT (PPTP) | 1169.23Mbps / 1175.52Mbps |
| IPsec VPN Throughput | ESP-MD5-AES256: 537.12Mbps |
| ESP-SHA1-AES256: 754.65Mbps | |
| L2TP VPN Throughput | Unencrypted: 1442.65Mbps |
| Encrypted: 346.43Mbps | |
| SSL VPN Throughput | 142.99Mbps |
| 66 Byte Packet Forwarding Rate | 1832.69Mbps / 1741.84Mbps |
| 1,518 Byte Packet Forwarding Rate | 2461.18Mbps / 2457.32Mbps |
| BASIC FUNCTIONS | |
| WAN Connection Type | IPv4_Static IP |
| IPv4_Dynamic IP | |
| IPv4_PPPOE | |
| IPv4_L2TP | |
| IPv4_PPTP | |
| IPv6_PPP | |
| IPv6_DHCPv6 | |
| IPv6_Static IP | |
| IPv6_6in4 | |
| IPv6_Pass-Through | |
| Mobile Broadband: 4G/3G modem for backup via USB port | |
| MAC Clone | Modify WAN/LAN MAC Address |
| DHCP | DHCP Server/Client |
| DHCP Address Reservation | |
| Multi-IP Interfaces | |
| Multi-Net DHCP | |
| IPv6 | WAN Connection |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy |
| ADVANCED FUNCTIONS | |
| Advanced Routing | Static Routing |
| Policy Routing | |
| Bandwidth Control | IP/Port-based Bandwidth Control |
| Guarantee and Limited Bandwidth | |
| Load Balance | Intelligent Load Balance |
| Application Optimized Routing | |
| Link Backup (Timing, Failover) | |
| Online Detection | |
| NAT | One-to-One NAT |
| Multi-Net NAT | |
| Port Forwarding | |
| Port Triggering | |
| NAT-DMZ | |
| FTP/H.323/SIP/IPSec/PPTP ALG | |
| UPnP | |
| Security | Attack Defense: |
| TCP/UDP/ICMP Flood Defense | |
| Block TCP Scan (Stealth FIN/Xmas/Null) | |
| Block Ping from WAN | |
| Filtering: | |
| Web Group Filtering | |
| URL Filtering | |
| Web Security | |
| ARP Inspection: | |
| Sending GARP Packets | |
| ARP Scanning | |
| IP-MAC Binding | |
| Access Control: | |
| Source/Destination IP Based Access Control | |
| Session Limit | IP-based Session Limit |
| VPN | |
| IPsec VPN | 100 IPSec VPN Tunnels |
| LAN-to-LAN, Client-to-LAN | |
| Main, Aggressive Negotiation Mode | |
| DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm | |
| IKEv1/v2 | |
| MD5, SHA1 Authentication Algorithm | |
| NAT Traversal (NAT-T) | |
| Dead Peer Detection (DPD) | |
| Perfect Forward Secrecy (PFS) | |
| PPTP VPN | PPTP VPN Server |
| PPTP VPN Clients (12) | |
| 60 Tunnels (Shared with L2TP) | |
| PPTP with MPPE Encryption | |
| L2TP VPN | L2TP VPN Server |
| L2TP VPN Clients (12) | |
| 60 Tunnels (Shared with PPTP) | |
| L2TP over IPSec | |
| OpenVPN | OpenVPN Server |
| OpenVPN Clients (6) | |
| 66 OpenVPN Tunnels | |
| AUTHENTICATION | |
| Web Authentication | No Authentication |
| Simple Password | |
| Hotspot (Local User/Voucher /SMS/Radius) | |
| External Radius Sever | |
| External Portal Sever | |
| MANAGEMENT | |
| Omada App | Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | Omada Cloud-Based Controller |
| Omada Hardware Controller (OC300) | |
| Omada Hardware Controller (OC200) | |
| Omada Software Controller | |
| Cloud Access | Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Maintenance | Web Management Interface |
| Remote Management | |
| Export and Import Configuration | |
| SNMP v1/v2c/v3 | |
| Diagnostics (Ping and Traceroute) | |
| NTP Synchronize | |
| Syslog Support | |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features | Automatic Device Discovery |
| Intelligent Network Monitoring | |
| Abnormal Event Warnings | |
| Unified Configuration | |
| Reboot Schedule | |
| Captive Portal Configuration | |
| ZTP (Zero-Touch Provisioning) | |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | ER707-M2 |
| Power Adapter | |
| Quick Installation Guide | |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux |
| Environment | Operating Temperature: 0~40°C |
| Storage Temperature: -40~70°C | |
| Operating Humidity: 10–90% RH non-condensing | |
| Storage Humidity: 5–90% non-condensing | |
