MERCUSYS MS106LP | 6-PORT 10/100MBPS DESKTOP SWITCH WITH 4-PORT POE+

FEATURES:

  • 6-Ports – 6× 10/100Mbps RJ45 ports with 4 PoE+ ports
  • Two Cables in One – With four PoE+ ports, transfers data and power on s single cable
  • High Power PoE+ – Supports PoE Power up to 30W for each PoE port and 40W for all PoE ports
  • 2× Uplink Ports – Provides 2× uplink ports when turning on isolation mode. One for connecting to the Internet and one for connecting to an NVR
  • Long-Range up to 250m – Increases PoE transmission distance up to 250m in Extend Mode
  • Isolation Mode – One click to divide traffic to specific ports for stability and security
  • Compliant with Powered Devices – Works with IEEE 802.3af/at compliant PDs
  • Durable Metal Casing – Allows for efficient heat dissipation and long network life
  • Plug and Play – Simple to use and saves time and effort
  • PoE Auto Recovery – Automatically reboots your dropped or unresponsive PoE-powered devices

18 in stock

SKU: NET-MER-MS106LP Categories: , , Tags: , , , , , , , ,

Mercusys MS106LP | 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+

FEATURES:

  • 6-Ports - 6× 10/100Mbps RJ45 ports with 4 PoE+ ports
  • Two Cables in One - With four PoE+ ports, transfers data and power on s single cable
  • High Power PoE+ - Supports PoE Power up to 30W for each PoE port and 40W for all PoE ports
  • 2× Uplink Ports - Provides 2× uplink ports when turning on isolation mode. One for connecting to the Internet and one for connecting to an NVR
  • Long-Range up to 250m - Increases PoE transmission distance up to 250m in Extend Mode
  • Isolation Mode - One click to divide traffic to specific ports for stability and security
  • Compliant with Powered Devices - Works with IEEE 802.3af/at compliant PDs
  • Durable Metal Casing - Allows for efficient heat dissipation and long network life
  • Plug and Play - Simple to use and saves time and effort
  • PoE Auto Recovery - Automatically reboots your dropped or unresponsive PoE-powered devices

SPECIFICATIONS:

HARDWARE
Dimensions 99.8 × 98 × 25mm
PoE Ports RJ45
Standard: Compliant with 802.3 af/at Powered Devices
PoE Ports: 1 to 4
PoE Power Budget: 40W
Interfaces 6× 10/100Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
External Power Supply External Power Adapter (Output: 53.5V 0.81A)
Installation Desktop
Wall Mount
Standards and Protocols IEEE 802.3x Flow Control
Data Rates 10/100Mbps at Half Duplex
20/200Mbps at Full Duplex
Jumbo Frame 2KB
Mac Address Table 2K
Max. Power Consumption 1.87W (220V 50Hz, no PD connected)
44.8W (220V 50Hz, with 40W PD connected)
Max. Heat Dissipation 6.34 BTH/h (no PD connected)
152.32 BTH/h (with 40W PD connected)
OTHERS
Package Contents 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (MS106LP)
Power Adapter
Quick Installation Guide
Environment Operating Temperature: 0°C~40°C
Storage Temperature: -40°C~70°C
Operating Humidity: 10%~90% RH non-condensing
Storage Humidity: 5%~95% RH non-condensing
